Cadillac XT5 Crossover (2016-2020)

MSRP 44095 USDNeoscore 41%NEX score 62%

Product Overview

Launched in the 2017 Model Year, XT5 is Cadillac's best-selling vehicle. This dynamic crossover sits between the newly-introduced XT4 and XT6 and presents a value-option for consumers in the premium segment.

Product Gallery

Photo 0of Cadillac XT5 Crossover (2016-2020)Photo 1of Cadillac XT5 Crossover (2016-2020)Photo 2of Cadillac XT5 Crossover (2016-2020)Photo 3of Cadillac XT5 Crossover (2016-2020)Photo 4of Cadillac XT5 Crossover (2016-2020)Photo 5of Cadillac XT5 Crossover (2016-2020)Photo 6of Cadillac XT5 Crossover (2016-2020)Photo 7of Cadillac XT5 Crossover (2016-2020)Photo 8of Cadillac XT5 Crossover (2016-2020)

<

>

X

Ratings

What we found**

Neoscore: 41% (not directly comparable across industries)
Pros
  • Some offroad capabilities
  • Decent design
  • Good on-road behavior
Cons
  • Stuck with MacPherson struts in the front

What external reviewers found***

NEX score: 62% (not directly comparable across industries)
Pros
  • Excellent infotainment system
  • Comfortable ride
  • Expansive interior
Cons
  • Mediocre fuel-economy
  • Fiddly electronic shifter
Read More

Find Related Products (incl. referral links)*

Specifications

Variants:
2.0 AT
2.0 AWD AT
3.6 AT
3.6 AWD AT

Capacity

Cargo Capacity
852 L (behind rear seats); 1784 L (rear seats folded)
2.0 ATCargo Capacity
849 L / 30.0 cu-ft ~ 1784 L / 63.0 cu-ft
2.0 AWD ATCargo Capacity
849 L / 30.0 cu-ft ~ 1784 L / 63.0 cu-ft
3.6 ATCargo Capacity
849 L / 30.0 cu-ft ~ 1784 L / 63.0 cu-ft
3.6 AWD ATCargo Capacity
850 L / 30.0 cu-ft ~ 1784 L / 63.0 cu-ft
2.0 ATCoolant Capacity
8.5 L / 9.0 qt
2.0 AWD ATCoolant Capacity
8.5 L / 9.0 qt
3.6 ATCoolant Capacity
11.3 L / 11.9 qt
3.6 AWD ATCoolant Capacity
11.3 L / 11.9 qt
2.0 ATEngine Oil Capacity
4.7 L / 5.0 qt
2.0 AWD ATEngine Oil Capacity
5.7 L / 6.0 qt
3.6 ATEngine Oil Capacity
5.7 L / 6.0 qt
3.6 AWD ATEngine Oil Capacity
5.7 L / 6.0 qt
2.0 ATFuel Capacity
72.0 L / 19.0 gal
2.0 AWD ATFuel Capacity
83.0 L / 21.9 gal
3.6 ATFuel Capacity
72.0 L / 19.0 gal
3.6 AWD ATFuel Capacity
83.0 L / 21.9 gal
Passengers
5
Payload
619 kg / 1365 lbs

Chassis

Brakes | Front
Ventilated discs
Brakes | Rear
Ventilated discs
Offroad | Approach Angle
15.8 deg
Offroad | Departure Angle
23.5 deg
Power Steering
Electric Steering
Suspension | Front
MacPherson strut
Suspension | Rear
Multi-link
Tire Size
235/65 R18, 235/55 R20
Turning Circle
11.8 m / 38.7 ft

Construction

Body Style
5-door SUV

Dimensions

Ground Clearance
200 mm / 7.9 in
Size | Height
1675 mm / 65.9 in
Size | Length
4815 mm / 189.6 in
Size | Width
1903 mm / 74.9 in
Track Width | Front
1638.0 mm / 64.5 in
Track Width | Rear
1638.0 mm / 64.5 in
Weight
1776 kg
2.0 ATWeight
1808.0 kg / 3986.0 lbs
2.0 AWD ATWeight
1931.0 kg / 4257.1 lbs
3.6 ATWeight
1931.0 kg / 4257.1 lbs
3.6 AWD ATWeight
1931.0 kg / 4257.1 lbs
Wheel Size
18 in, 20 in
Wheelbase
2857 mm / 112.5 in

Performance

Acceleration | 0 - 100 km/h
7.5 sec
Acceleration | 0 - 60 mph
7.1 sec
CO2 Emission
229 g/km
Coefficient Of Drag
0.32
2.0 ATFuel Economy
11.8 L/100km / 19.9 MPG (urban) | 8.7 L/100km / 27.0 MPG (highway)
2.0 AWD ATFuel Economy
12.4 L/100km / 19.0 MPG (urban) | 9.0 L/100km / 26.1 MPG (highway)
3.6 ATFuel Economy
12.4 L/100km / 19.0 MPG (urban) | 8.7 L/100km / 27.0 MPG (highway)
3.6 AWD ATFuel Economy
10.0 L/100km / 23.5 MPG (combined) | 14.1 L/100km / 16.7 MPG (urban) | 7.6 L/100km / 31.0 MPG (highway)
Top Speed
210.0 km/h / 130.5 mph
Towing Capacity
1558 kg (3.6L)
2.0 ATTowing Capacity
1588 kg / 3501 lbs (w/ brakes @ 12% gradient)
2.0 AWD ATTowing Capacity
1588 kg / 3501 lbs (w/ brakes @ 12% gradient)
3.6 ATTowing Capacity
1588 kg / 3501 lbs (w/ brakes @ 12% gradient)
3.6 AWD ATTowing Capacity
454 kg / 1001 lbs (w/o brakes) | 2000 kg / 4409 lbs (w/ brakes @ 12% gradient)

Powertrain

2.0 ATDrivetrain Layout
Front-engine (transverse), Front-wheel drive
2.0 AWD ATDrivetrain Layout
Front-engine (transverse), All-wheel drive
3.6 ATDrivetrain Layout
Front-engine (transverse), Front-wheel drive
3.6 AWD ATDrivetrain Layout
Front-engine (longitudinal), All-wheel drive
Emission Standard
Euro 6
2.0 ATEngine
LTG
2.0 AWD ATEngine
LTG
3.6 ATEngine
LGX
3.6 AWD ATEngine
LGX
2.0 ATEngine | Bore
86.0 mm / 3.4 in
2.0 AWD ATEngine | Bore
86.0 mm / 3.4 in
3.6 ATEngine | Bore
95.0 mm / 3.7 in
3.6 AWD ATEngine | Bore
95.0 mm / 3.7 in
2.0 ATEngine | Compression Ratio
9.5:1
2.0 AWD ATEngine | Compression Ratio
9.5:1
3.6 ATEngine | Compression Ratio
11.5:1
3.6 AWD ATEngine | Compression Ratio
11.5:1
2.0 ATEngine | Displacement
2.0 L / 121.9 cu-in / 1998.0 cc
2.0 AWD ATEngine | Displacement
2.0 L / 121.9 cu-in / 1998.0 cc
3.6 ATEngine | Displacement
3.6 L / 222.7 cu-in / 3649.0 cc
3.6 AWD ATEngine | Displacement
3.6 L / 222.7 cu-in / 3649.0 cc
2.0 ATEngine | Power
261.0 hp / 194.6 kW @ 5300 rpm
2.0 AWD ATEngine | Power
261.0 hp / 194.6 kW @ 5300 rpm
3.6 ATEngine | Power
314.0 hp / 234.1 kW @ 6700 rpm
3.6 AWD ATEngine | Power
314.0 hp / 234.1 kW @ 6700 rpm
2.0 ATEngine | Redline
7000 rpm
2.0 AWD ATEngine | Redline
7000 rpm
3.6 ATEngine | Redline
7200 rpm
3.6 AWD ATEngine | Redline
7200 rpm
2.0 ATEngine | Specific Output
130.6 hp/L / 2.1 hp/cu-in
2.0 AWD ATEngine | Specific Output
130.6 hp/L / 2.1 hp/cu-in
3.6 ATEngine | Specific Output
86.1 hp/L / 1.4 hp/cu-in
3.6 AWD ATEngine | Specific Output
86.1 hp/L / 1.4 hp/cu-in
2.0 ATEngine | Stroke
86.0 mm / 3.4 in
2.0 AWD ATEngine | Stroke
86.0 mm / 3.4 in
3.6 ATEngine | Stroke
85.8 mm / 3.4 in
3.6 AWD ATEngine | Stroke
85.8 mm / 3.4 in
2.0 ATEngine | Torque
400 Nm / 295.0 lb-ft @ 3000 rpm
2.0 AWD ATEngine | Torque
400 Nm / 295.0 lb-ft @ 3000 rpm
3.6 ATEngine | Torque
367 Nm / 270.7 lb-ft @ 5000 rpm
3.6 AWD ATEngine | Torque
368 Nm / 271.4 lb-ft @ 5000 rpm
2.0 ATEngine | Type
Naturally-aspirated direct-injected petrol inline-4 DOHC engine with 4 values per cylinder
2.0 AWD ATEngine | Type
Naturally-aspirated direct-injected petrol inline-4 DOHC engine with 4 values per cylinder
3.6 ATEngine | Type
Naturally-aspirated direct-injected petrol V6 DOHC engine with 4 values per cylinder
3.6 AWD ATEngine | Type
Naturally-aspirated direct-injected petrol V6 DOHC engine with 4 values per cylinder
2.0 ATFinal Drive
3.47
2.0 AWD ATFinal Drive
3.49
Fuel Capacity
FWD: 73.4 L, AWD: 82.1 L
Transmission | Gears
8-speed
Transmission | Type
Automatic

Production

Availability
2016 ~ 2020
Debut
2015 LA Auto Show
Made In
US: Tennessee; China: Shanghai
