Yamaha A-S2200 Integrated Amplifier
Product Gallery
Product Overview
Yamaha A-S2200 features a fully balanced circuit with floating design and a fully discrete headphone amplifier. Compared to its smaller sibling, the A-S1200, the A-S2200 adds a pair of balanced inputs, too.
Up front, the A-S2200 features a set of beautiful level meters that add drama and nostalgia to the listening experience. Thick wires for ground connection adds to the low-impedance amplifier design, resulting in a wide and open sound stage. The Mechanical Ground Concept in the Yamaha A-S2200 maximizes rigidity and reduces vibration.
Ratings
Product not yet rated.
Price Comparison
Specifications
Connectivity
Ports
4x RCA, XLR, Phono
Dimensions
Size | Depth
463 mm
Size | Height
157 mm
Size | Width
435 mm
Weight
22.7 kg / 50.0 lbs
Performance
Damping Factor
≧ 250 (1 kHz, 8 ohms)
Frequency Response
+0 / -3 dB (5 Hz-100 kHz) , ＋0 / -0.3 dB(20 Hz-20 kHz)
Power Output
2x 160W (4 ohms, 1kHz, 0.7% THD, EU) / 2x 90W (8 ohms, 20-20kHz, 0.07% THD, US) / 2x 150W (4 ohms, 20-20kHz, 0.07% THD)
RIAA Equalization Deviation
+/-0.5 dB
Signal-to-Noise Ratio
PHONO MC: 90 db, PHONO MM: 96 dB, CD, etc.: 110 dB, BAL: 114 dB
Production
Debut
2020-04-07
